CWH3 Hanger for Aluminium Frames 50 pack
£14.44 Ex Vat
Out of Stock
More expected Wednesday 16 Feb 22
6927A CWH3 Hanger for Aluminium Frames 50 pack
CWH3 Hanger - suitable for most aluminium frame profiles
Fits easily into the channel of most double-plate aluminium frame profiles. Adjusted with two screws, included. Hang CWH hangers directly on hooks or screws. No need to use picture cord or wire.
Fit CWH3 Hangers in 4 simple steps:
1) Slot 2 CWH Hangers into the aluminium frame. Position and mark approximately 1/3 of the way down from the top. Put one screw in an oval hole of each hanger.
2) Position and fix the hooks, place two Post-its in approximate hook positions. Check and mark hook positions on Post-its. Hold hook in position on mark. Use a light hammer to insert pins.
3) Hang frame in place on the hooks and check for general position. To adjust for level, use screw in a slot. To lock CWH Hangers in position, insert second screw in each.
4) Frames will hang flat and level on the wall - do not tip forward.
Also available in a pack of 20.
Safe working load, based on our tests: 11kg (when used in pairs)
Screws in CWH3 Square Sawtooth Hangers - screws included in this pack are sometimes slotted and sometimes cross headed. If slotted use a well-fitting flat bladed screwdriver. If cross-headed use a PH-2 screwdriver head.
We have an in-house purpose-built load testing rig so you can be more certain of the safe load carrying capacity of any frame hardware from Lion.
SWL – Red handle icon giving a tested safe load figure which is derived from actual test results on our rig. Typically between 25% and 33% of the load at failure.
ESWL – White handle icon shows an estimated safe load figure based on our experience and best judgement.
